KB60180M47FV: 6-18GHz Wideband 50W Power Amplifier Module

To meet the urgent needs of radar and electronic warfare applications for wideband, high-reliability power amplifiers, KeyLink highlights its X/Ku-band solid-state power amplifier module—the KB60180M47FV. With its superior ultra-wideband performance and over 100 units in stock, this model provides global customers with a readily available, high-performance RF front-end solution.

The KB60180M47FV is a wideband amplifier designed based on advanced GaN and GaAs technologies, with performance parameters precisely matched to the stringent requirements of modern electronic systems:

1. Ultra-wide operating frequency band: Covering 6GHz to 18GHz, meeting the application requirements of X-band and part of Ku-band.

2. Stable power output: Providing 50W of continuous wave (CW) output power with a gain of 47dB, ensuring signal strength and purity.

3. Compact and Efficient Design: The module measures only 180 x 120 x 22 mm and operates on 28V DC power, facilitating integration into various compact systems.

4. Protection Functions: The product features built-in protection against standing waves, overvoltage, overcurrent, and overtemperature.

5. Strong In-Stock Support: Currently, over 100 units are in stock, supporting sample requests and rapid small-batch delivery, significantly shortening customers' R&D and production cycles.

Typical Application Areas: The high efficiency and wideband characteristics of the KB60180M47FV make it ideal for the following applications:

l Electronic Countermeasures (Jamming): Wideband jamming signal generation.

l Radar Systems: Transmitter front-end drive or excitation stage.

l Communication Links: Point-to-point wideband communication.

l Test and Measurement: Wideband signal amplification and simulation.

Expanding the Product Family

Based on the same 6-18GHz wideband platform, KeyLink offers a complete range of power ratings and integration options, providing customers with flexible performance upgrade paths:

KB60180M40FV: 6-18GHz 10W

KB60180M43FV: 6-18GHz 20W

KB60180M45FV: 6-18GHz 30W

KB60150M49FV: 6-18GHz 80W

KB60150M51FV: 6-18GHz 120W

KeyLink is a leading global RF technology company, dedicated to providing high-performance, high-reliability solid-state power amplifiers, RF components, and system solutions for radar, electronic warfare, communications, and test and measurement applications. The company's products cover the 1MHz to 46GHz frequency band, with power ranging from watts to kilowatts. All products are designed and manufactured based on cutting-edge semiconductor technology, ensuring superior wideband efficiency and high reliability.

If you are interested in the KB60180M47FV or any amplifier in the 6-18GHz band, please visit the KeyLink website product page for detailed specifications, or contact our sales team and technical engineers directly. For customers planning to attend Expo Electronica 2026 (April 14-16, Moscow), we welcome you to schedule an appointment at our booth C-20B for in-depth technical discussions and to see a live demonstration of the product.
